Scotsman CU3030 - Cabinet Layouts; CU1526 & CU2026 Cabinet Layout Diagram

CU3030 Cabinet Layout
May 2008
Page 6
CU1526, CU2026, CU3030
Service Manual
5.30
13.5
39.0
99.0
25.95
65.9
4.69
11.9
30.0
76.2
30.62
77.8
4.00
MINIMUM
UTILITY
CLEARANCE
10.2
6.00
15.2
24.25
61.6
29.63
75.3
6.99
17.7
3.19
8.1
4.33
11
29.36
74.6
2.77
7
4.65
11.8
6.27
15.9
23.82
60.5
DRAIN
3/4 FPT
COND WATER
REGULATOR
3/8 NPT
(W/C ONLY)
COND DRAIN
1/2 NPT
(W/C ONLY)
POTABLE
WATER INLET
3/8 FLARE
POWER CORD
