Installation
Installation steps:
 Be sure the ice maker is level (level the
machine with the supplied legs in the
storage bin)
 Connect the water supply with the supplied
pipe.
 Set the supplied water drain pipe on the
drain outlet; be sure there is a minimum 3
cm drop per meter.
 Turn on the water supply switch.
 Plug the power source plug into the socket.
 Press the power switch button to ‘on’
position.
(Installation chart)
Air Outlet
Air Inlet
10～40 ℃
Important：
The ice maker should be installed by an authorized
maintenance personnel.
