NUUndercounterIceMakerUserManual Summary
B3
Summary
The NU100/150/220/300 commercial ice maker
in this manual is electronically controlled; it is
equipped with an advanced and unique
electronic control system, which can control the
operation of the ice maker automatically. When
the storage bin is full of ice, the ice maker will
stop working automatically and restart working
again when the bin is no longer full.
Model
Item
NU100 NU150 NU220 NU300
Capacity
(24 hours) ①
[kg]
45 68 100 132
Power
[V/Hz/
ph]
220/50/
1
220/50/1
220/50/1 220/50/1
(Size)
(width) mm
600 600 650 650
(depth) mm
610 610 690 690
(height with short foot)
(height with high foot)
mm
770
875
770
875
870
976
898
1004
Power cord [Ø mm
2
]
1.5 1.5 1.5 1.5
Power input # [W]
900 1000 1200 1500
Power consumption ①
[KWh/100lbs]
8 5.6 5.9 6.5
Power consumption ②
[KWh/100lbs]
12.6 8.5 8.5 9
Water consumption ①
[Gal/100lbs]
32 20 19 20
Water consumption ②
[Gal/100lbs]
32 20 19 20
Net weight [kg]
50 50 62 65
Cooling type
Air Air
Air Air
Refrigerant
R404a R404a R404a R404a
Charge
320 g 320 g 360 g 420g
# Maximum working condition
① At 21℃ (70℉) ambient temperature/10℃
(50℉) water temperature
② At 32℃ (90℉) ambient temperature/21℃
(70℉) water temperature
Notes: The manufacture reserves the right to
change the model or specifications of the
product without further notice.
