Page 3 of 48 P/N 595279-01 Rev. B 5/14
2
Portacount Plus is a registered trademark of TSI Incorporated
WARNING
BATTERIES ARE REQUIRED FOR PROPER
OPERATION OF THIS EQUIPMENT. FAILURE
TO INSTALL BATTERIES AND TO PERFORM
A REGULAR OPERATIONAL INSPECTION
MAY RESULT IN A MALFUNCTION OF THE
EQUIPMENT WHICH COULD RESULT IN SE-
RIOUS INJURY OR DEATH.
WARNING
USE OR MISUSE OF THIS RESPIRATOR IN
SUCH A MANNER AS TO EXPOSE THE USER
TO THE ATMOSPHERE THE RESPIRATOR
IS INTENDED TO PROTECT AGAINST MAY
RESULT IN SERIOUS INJURY OR DEATH.
QUESTIONS OR CONCERNS
If you have any questions or concerns regarding use of this equipment,
contact your authorized SCOTT distributor, or contact SCOTT at 1-800-
247-7257 (or 704-291-8300 outside the continental United States).
For all NFPA compliant versions of this respirator, report any operational
malfunctions to the certication agency Safety Equipment Institute (SEI),
1307 Dolley Madison Blvd.. Suite 3A, McLean, VA 22101, (703) 442-5732,
Fax (703) 442-5756.
For all NIOSH compliant versions of this respirator, report any complaints of
damage, malfunction or failure of the breathing apparatus that may represent
a hazard to the user to the certication agency NIOSH/NPPTL /Respirator
Branch, P.O. box 18070, Pittsburgh, PA 15236, (412) 386-4000.
EXPORT AND IMPORT
The international transport of this equipment and portions thereof is
regulated under United States export regulations and may be regulated
by the import regulations of other countries.
If you have any questions or concerns regarding these regulations, con-
tact SCOTT at 1-800-247-7257 (or 704-291-8300 outside the continental
United States).
The AV-3000 HT Facepiece is made of heat resistant materials. When using
the AV-3000 HT Facepiece in applications where high heat may occur,
follow all training and operating procedures relating to heat exposure. To
avoid possible injury, the respirator user must understand the hazards
of heat exposure including temperature, duration and repeat exposure.
The removable pressure-demand breathing regulator mounts directly to
the facepiece and is equipped with an Air Saver/Donning Switch and a
red Purge Knob.
All models of the AIR-PAK X3 SNAP-CHANGE SCBA respirator are equipped
with the VIBRALERT alarm in the facepiece mounted regulator. The
VIBRALERT alarm serves two functions: as an end of service time indicator
and to alert the user of a malfunction in the dual path pressure reducer. In
normal operation, the VIBRALERT alarm vibrates the breathing regulator
and facepiece to warn the user by both sound and feel that approximately
33% of full cylinder pressure remains. In addition, if the primary air path of
the pressure reducer becomes blocked or should fail closed, the secondary
air path will automatically begin supplying air to the breathing regulator and
the VIBRALERT alarm will be actuated to warn the user of the malfunction.
The HEADS-UP DISPLAY is an independent end of service time indicator
alarm attached to the facepiece mounted regulator and is standard on
respirators required to have two independent redundant alarms. The
HEADS-UP DISPLAY provides a visual monitor of the air supply with
four lights that appear just below the facepiece field of vision. A separate
low battery light warns the user that the batteries must be replaced. The
HEADS-UP DISPLAY detects cylinder pressure directly and is totally
independent of the VIBRALERT.
Whenever any end of service indicator alarm or alarms actuate, the user
must leave the area requiring respiratory protection immediately.
This respirator is tted with a Rapid Intervention Crew/Company Universal Air
Connection (RIC UAC) System which permits emergency replenishment of an
approved SCBA breathing air supply cylinder from an approved air supply source
while in use. This is not a Quick Charge attachment and must not be used for routine
recharging of the cylinder, for “buddy breathing”, for transferring air from another
SCBA cylinder, or any unapproved use. The RIC UAC is for emergency use only
when the respirator user is incapacitated within the hazardous atmosphere.
Batteries are required for the proper operation of this equipment. Refer
to the BATTERY REPLACEMENT section of this instruction for details of
installation.
WARNING
THE AV-3000 HT FACEPIECE IS MADE OF
HEAT RESISTANT MATERIALS. WHEN USING
THE AV-3000 HT FACEPIECE, FOLLOW ALL
TRAINING AND OPERATING PROCEDURES
RELATING TO HEAT EXPOSURE. THE
RESPIRATOR USER MUST UNDERSTAND
THE HAZARDS OF HEAT EXPOSURE
INCLUDING TEMPERATURE, DURATION,
AND REPEAT EXPOSURE. FAILURE TO DO
SO MAY RESULT IN SERIOUS INJURY OR
DEATH.
