4
1
Kevlar is a registered trademark of E.I. du Pont de Nemours, Inc.
2
Portacount
®
Plus is a registered trademark of TSI Incorporated
WARNING
THIS RESPIRATOR, IS INTENDED TO
PROTECT THE USER ONLY FROM THE
EFFECTS OF AN OXYGEN DEFICIENT AT-
MOSPHERE AND/OR ATMOSPHERES
CONTAINING TOXIC OR HAZARDOUS
SUBSTANCES BY PROVIDING A SUPPLY
OF RESPIRABLE BREATHING AIR TO A
FACEPIECE SEALED TO THE USER'S FACE.
SOME TOXIC OR HAZARDOUS ATMO-
SPHERES CONTAIN SUBSTANCES WHICH
CAN POISON BY ABSORPTION THROUGH
EXPOSED SKIN. FAILURE TO TAKE ALL
NECESSARY PRECAUTIONS WHEN ENTER-
ING A HAZARDOUS ATMOSPHERE MAY
RESULT IN SERIOUS INJURY OR DEATH.
GENERAL DESCRIPTION
The SCOTT AIR-PAK NxG
2
self contained breathing apparatus
(SCBA) is a respirator which, when properly maintained and properly
used, is intended to provide respiratory protection to an individual
when entering into, working in and exiting an objectionable, an oxy-
gen deficient and/or unbreathable (toxic) atmosphere.
The SCOTT AIR-PAK NxG
2
SCBA is to be used only by persons
trained in the use of the respirator and only in conjunction with an
organized respiratory protection program. The SCBA is not to be used
for purposes other than authorized by your respiratory protection pro-
gram. For example, this respirator must not be used underwater.
The SCOTT AIR-PAK NxG
2
SCBA consists of, at a minimum, a cylin-
der and valve assembly to store a supply of breathing air under
pressure, a backframe and harness assembly to support the cylinder
and valve assembly and pressure reducer on the body, a backframe
mounted pressure reducer to supply air to the breathing regulator, a
facepiece mounted pressure demand breathing regulator, an approved
SCOTT full facepiece and a head harness to secure the facepiece to
the face. All SCOTT AIR-PAK NxG
2
SCBA's described in this instruc-
tion are equipped with an end of service indicator, a remote pressure
gauge mounted on the wearer's right shoulder strap and an air saver
switch located on top of the breathing regulator. All model respirators
described by these instructions are equipped with shoulder straps,
waist straps and head harnesses made of Kevlar
1
.
The typical facepiece design incorporates a nose cup, two inhalation
valves and dual voicemitter assemblies which are integral parts of the
approved respirator assembly. The facepiece may be readily detached
from the breathing regulator to allow for utilization of the best fitting
facepiece for an individual user.
The approved facepiece utilized by the SCBA's described by this in-
struction is available in a variety of models and sizes. Users of this
respirator must be properly fitted to a facepiece and trained in the
use of that facepiece with the respirator. The facepiece must be fit-
ted using qualitative or quantitative fit testing procedures in
accordance with OSHA Standard 29 CFR Part 1910 (Occupational
Safety and Health Standards). See also ANSI Standard Z88.2. For
testing in the negative pressure mode using equipment such as a
Portacount
®
Plus
2
Respirator Fit Tester, SCOTT facepieces require
use of SCOTT Fit Test Adapter P/N 804057-01. Mask Seal Kit P/N
805655-01 may also be required to attain a proper fit.
WARNING
DO NOT OPERATE THIS EQUIPMENT
WHILE UNDER THE INFLUENCE OF
DRUGS, ALCOHOL, OR ANY MEDICATIONS
OR SUBSTANCES WHICH MAY AFFECT VI-
SION, DEXTERITY, OR JUDGMENT. USERS
OF THIS EQUIPMENT MUST BE IN GOOD
PHYSICAL AND MENTAL HEALTH IN ORDER
TO OPERATE SAFELY. DO NOT USE THIS
EQUIPMENT WHEN FATIGUE PREVENTS
SAFE OPERATION. STAY ALERT WHEN
OPERATING THIS EQUIPMENT. INATTEN-
TION OR CARELESSNESS WHILE
OPERATING THIS EQUIPMENT MAY RE-
SULT IN SERIOUS INJURY OR DEATH.
WARNING
FIT TESTING IN ACCORDANCE WITH OSHA
STANDARD 29 CFR PART 1910 IS RE-
QUIRED AS PART OF THE REQUIRED
TRAINING BEFORE USE OF THIS RESPIRA-
TOR. FAILURE TO PROPERLY FIT AND
TRAIN THE USER IN USE OF THE FACE-
PIECE AND RESPIRATOR MAY RESULT IN
EXPOSURE TO THE HAZARDOUS ATMO-
SPHERE WHICH COULD LEAD TO SERIOUS
INJURY OR DEATH.
WARNING
IMPROPER USE OF THIS RESPIRATOR MAY RESULT IN PERSONAL INJURY OR DEATH. IMPROPER USE
INCLUDES, BUT IS NOT LIMITED TO, USE WITHOUT ADEQUATE TRAINING, DISREGARD OF THE WARN-
INGS AND INSTRUCTIONS CONTAINED HEREIN, AND FAILURE TO INSPECT AND MAINTAIN THIS RESPIRATOR.
READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE ATTEMPTING TO OPERATE OR SERVICE THIS EQUIP-
MENT.
THIS RESPIRATOR IS INTENDED TO BE USED ONLY IN CONJUNCTION WITH AN ORGANIZED RESPIRA-
TORY PROTECTION PROGRAM WHICH COMPLIES WITH THE REQUIREMENTS OF "PRACTICES FOR
RESPIRATORY PROTECTION," Z88.2 AVAILABLE FROM AMERICAN NATIONAL STANDARDS INSTITUTE INC.,
1430 BROADWAY, NEW YORK, N.Y., 10018, OR THE REQUIREMENTS OF OSHA SAFETY AND HEALTH
STANDARD 29 CFR 1910 PARAGRAPH 134 AVAILABLE FROM THE U. S. DEPARTMENT OF LABOR, OC-
CUPATIONAL SAFETY AND HEALTH ADMINISTRATION, OR OTHER PERTINENT NATIONALLY RECOGNIZED
STANDARDS, SUCH AS THOSE PROMULGATED BY THE US COAST GUARD OR THE DEPARTMENT OF DEFENSE.
