Main unit with speaker boxes (front view)
Remote control
1. VOLUME +/- (2x)
2. MUTE
3. OPEN/CLOSE
4. SOURCE
5. EQ (Equalizer)
6. ON/STANDBY
7. XBASS(Bass boost)
8. ENTER/ ST/MO
9. REPEAT
10. RANDOM
11. NEXT
12. INTRO
13. ID3 display
14. STOP /BAND
15. PRESET/FOLDER
16. PLAY/ PAUSE
17. CLOCK set
18. PREVIOUS
19. PRESET/FOLDER
20. MENU/MEMORY
1. Bass reflex hole
2. SOURCE button
3. ENTER/ ST/MO (stereo/mono) button
4. LCD display
5. iPod universal dock and connector
6. Infra-red remote sensor
7. PLAY/ PAUSE button
8. STOP /BAND button
9. Tweeter (speaker with high frequency sound output)
10. Speaker
11. OPEN/CLOSE button
12. MEMORY button
13. NEXT button
14. PREVIOUS button
15. VOLUME knob
16. SD/MMC card slot
17. CD tray
18. USB port
19. Headphones jack
20. PRESET/FOLDER button
21. PRESET/FOLDER button
22. ON/STANDBY button
23. Standby led indicator
GB-3
1 12 3 4
5
6 7 8
99
10 10
11
12
13
14
15161719 18
20
21
23
22
