P/N 595225-01 Rev C 4/12
FIGURE 4
EMERGENCY FACEPIECE AND REGULATOR
AIR SAVER
SWITCH
EMERGENCY
FACEPIECE
EMERGENCY
REGULATOR
PURGE
VALVE
FIGURE 3
DUAL LOW PRESSURE CONNECTOR
WITH ALTERNATE QUICK
DISCONNECT INSTALLED
(SEE PAGE 34)
COVER
CHECKED
MALE
FEMALE
FIGURE 2
HIGH PRESSURE CONNECTOR
HIGH PRESSURE
CONNECTOR COVER
