SCOTT SCALE 940 - LEGEND; Maintenance Symbols; Tooling and Difficulty Indicators

2023 SCALE | ENGLISH 2
|
SCALE
GEOMETRY & TECHNICAL DATA 03
HEADSET ADJUSTMENT 05
RIDELOC 06
CABLE ROUTING 07
SPARE PARTS 08
MANUFACTURE’S GUARANTEE 10
LEGEND
T 2
10 Nm
TORQUE REQUIRED
TORX TOOL SIZE
HEX TOOL SIZE
TORQUE AMOUNT
TASK DIFFICULTY
NO GREASE REQUIRED
GREASE REQUIRED
CARBON GREASE REQUIRED
THREADLOC REQUIRED
CONTENT
THE SCALE SHOULD BE ADJUSTED EXACTLY TO THE RIDER FOR MAXIMUM SAFETY AND
RIDEABILITY.
Please contact your authorized SCOTT dealer for advice in order to avoid technical problems or any harm.
BEARING FIT REQUIRED
