SCOTT SCALE 940 User Manual

2023 SCALE | ENGLISH 5
|
SCALE
It is important to install the headset correctly
depending on the set up required. There are
two types of headset cups.
0° & 0.6° ( 64° & 65°) These can be indentified
from the stamp on the inner surface of the
headset cup
The headset is available in two options:
288251 SYN HEADSET ZS56/28.6-ZS56/40 MTB
290060 SCO HEADSET CUP KIT SPARK 22
Do not use a standard headset tool
to remove these plastic headset
cups.
SCALE
HEADSET ADJUSTMENT
Slacker
Steeper

SCOTT SCALE 940 Specifications

General

Brakes	Shimano MT201 Disc
Chain	KMC X12
Saddle	Syncros Belcarra Regular 2.5
Frame	Boost 148x12mm
Fork	RockShox Judy Silver TK, 100mm travel
Shifters	Shimano Deore SL-M6100
Crankset	Shimano FC-MT511-1 / 32T
Cassette	Shimano Deore CS-M6100-12 / 10-51 T
Wheelset	Syncros / 32H
Tires	29x2.25"
Handlebar	Syncros Alloy 6061 / 740mm
Seatpost	Syncros / 31.6mm
BB-Set	Shimano BB-MT500
Rotor	Shimano SM-RT10 CL / 180/F and 160/R
H'stem	Syncros FL1.0
Headset	Syncros OE Press Fit
Hub (Front)	Formula CL-811
Hub (Rear)	Formula CL-3248
Spokes	Stainless Black 15G / 1.8mm
