SCOTT SCALE 940 User Manual

2023 SCALE | ENGLISH 4
|
SCALE
SCALE
GEOMETRY & TECHNICAL DATA CONT.
The rear brake calliper is a post mounted 160mm
without an adapter.
The maximum rotor size is 180mm, except on
a small size frame where it must not exceed
160mm.
If you wish to use two piston brake callipers, you
must check the clearance, as not all two piston
brakes will fit.
Please note that on a small size frame it is
only possible to use a 500 ml water bottle,
with a side entry cage.
Carbon frames will have a unique insert for
the rear axle.

SCOTT SCALE 940 Specifications

General

Brakes	Shimano MT201 Disc
Chain	KMC X12
Saddle	Syncros Belcarra Regular 2.5
Frame	Boost 148x12mm
Fork	RockShox Judy Silver TK, 100mm travel
Shifters	Shimano Deore SL-M6100
Crankset	Shimano FC-MT511-1 / 32T
Cassette	Shimano Deore CS-M6100-12 / 10-51 T
Wheelset	Syncros / 32H
Tires	29x2.25"
Handlebar	Syncros Alloy 6061 / 740mm
Seatpost	Syncros / 31.6mm
BB-Set	Shimano BB-MT500
Rotor	Shimano SM-RT10 CL / 180/F and 160/R
H'stem	Syncros FL1.0
Headset	Syncros OE Press Fit
Hub (Front)	Formula CL-811
Hub (Rear)	Formula CL-3248
Spokes	Stainless Black 15G / 1.8mm
