SCOTT SCALE 950 User Manual

2023 SCALE | ENGLISH 4
|
SCALE
SCALE
GEOMETRY & TECHNICAL DATA CONT.
The rear brake calliper is a post mounted 160mm
without an adapter.
The maximum rotor size is 180mm, except on
a small size frame where it must not exceed
160mm.
If you wish to use two piston brake callipers, you
must check the clearance, as not all two piston
brakes will fit.
Please note that on a small size frame it is
only possible to use a 500 ml water bottle,
with a side entry cage.
Carbon frames will have a unique insert for
the rear axle.

SCOTT SCALE 950 Specifications

General

Brakes	Shimano MT201 Disc
Chain	KMC X12
Saddle	Syncros Belcarra Regular 2.5
Rotor	Shimano SM-RT10 CL / 180/F and 160/R
Spokes	Stainless Black 15G / 1.8mm
Frame	Boost 12x148mm / Tapered Headtube / Internal Cable Routing
Fork	RockShox Judy Silver TK Solo Air / 100mm travel
Rear Derailleur	Shimano Deore RD-M6100 SGS Shadow Plus / 12 Speed
Shifters	Shimano Deore SL-M6100-R / 12 Speed
Crankset	Shimano FC-MT511-1, 32T
Cassette	Shimano Deore CS-M6100-12 / 10-51 T
Wheelset	Syncros / 32H
Tires	Schwalbe Rapid Rob 29x2.25" / Active line
Handlebar	Syncros Alloy 6061, T shape Flat / 9° / 740mm
Seatpost	Syncros / 31.6mm
H'stem	Syncros Alloy 6061 31.8mm
Headset	Syncros OE Press Fit / Tapered 1.5"-1 1/8"
Hub (Front)	Formula CL-811 / 15x100mm
Hub (Rear)	Boost 12x148mm
