SCOTT SCALE 950 User Manual

2023 SCALE | ENGLISH 3
|
SCALE
GEOMETRY & TECHNICAL DATA
SEATPOST
mm 31.6 (use carbon grease)
SEATPOST CLAMP
mm 34.9
TRAVEL
mm 100 Ft
SHOCK LENGTH
mm 185
MAX ROTOR
mm 180 Rr/Ft (160 Rr Small)
MAX CHAINRING
Tooth 38
MAX TYRE WIDTH
in 2.5
CHAINLINE
mm 55
N
O
P
Alloy/Carbon Alloy/Carbon Alloy/Carbon Alloy/Carbon Alloy
MY23 SCALE SM MED LG XL XXL
A Head tube angle
° 67.4/67.9 67.4/67.9 67.4/67.9 67.4/67.9 67.4
B Head tube length
mm 90/90 100/95 110/110 120/120 120
C Top tube horizontal
mm 580/575 605/600 630/626 660/656.5 680
D standover height
mm 755/752 786/781 805/800 835/835.1 870
E BB offset
mm -60/-62 -60/-62 -60/-62 -60/-62 -60/-62
F BB height
mm 315/313 315/313 315/313 315/313 315
G Wheelbase
mm 1111.8/1105.4 1138.2/1131.1 1164.6/1158 1195.9/1189.4 1215.9
I BB center to TST
mm 390/390 440/440 480/480 530/530 580
J Seat angle
°
75/75.4 75/75.4 75/75.3 75/75.3 75
K Chainstay
mm 425/425 425/425 425/425 425/425 425
L Reach
mm 420.3/418.5 442.8/442.3 463.3/463.6 492.9/491.2 512.9
M Stack
mm 596.1/600.3 605.3/604.9 614.6/618.9 623.8/628.1 623.8
Fork Rake
mm 44 44 44 44 44
Trail
mm
112.6/105.1 112.6/105 112.6/105 112.6/105 112.6

SCOTT SCALE 950 Specifications

General

Brakes	Shimano MT201 Disc
Chain	KMC X12
Saddle	Syncros Belcarra Regular 2.5
Rotor	Shimano SM-RT10 CL / 180/F and 160/R
Spokes	Stainless Black 15G / 1.8mm
Frame	Boost 12x148mm / Tapered Headtube / Internal Cable Routing
Fork	RockShox Judy Silver TK Solo Air / 100mm travel
Rear Derailleur	Shimano Deore RD-M6100 SGS Shadow Plus / 12 Speed
Shifters	Shimano Deore SL-M6100-R / 12 Speed
Crankset	Shimano FC-MT511-1, 32T
Cassette	Shimano Deore CS-M6100-12 / 10-51 T
Wheelset	Syncros / 32H
Tires	Schwalbe Rapid Rob 29x2.25" / Active line
Handlebar	Syncros Alloy 6061, T shape Flat / 9° / 740mm
Seatpost	Syncros / 31.6mm
H'stem	Syncros Alloy 6061 31.8mm
Headset	Syncros OE Press Fit / Tapered 1.5"-1 1/8"
Hub (Front)	Formula CL-811 / 15x100mm
Hub (Rear)	Boost 12x148mm
