SCOTT SCALE 950 User Manual

2023 SCALE | ENGLISH 5
|
SCALE
It is important to install the headset correctly
depending on the set up required. There are
two types of headset cups.
0° & 0.6° ( 64° & 65°) These can be indentified
from the stamp on the inner surface of the
headset cup
The headset is available in two options:
288251 SYN HEADSET ZS56/28.6-ZS56/40 MTB
290060 SCO HEADSET CUP KIT SPARK 22
Do not use a standard headset tool
to remove these plastic headset
cups.
SCALE
HEADSET ADJUSTMENT
Slacker
Steeper

SCOTT SCALE 950 Specifications

General

Brakes	Shimano MT201 Disc
Chain	KMC X12
Saddle	Syncros Belcarra Regular 2.5
Rotor	Shimano SM-RT10 CL / 180/F and 160/R
Spokes	Stainless Black 15G / 1.8mm
Frame	Boost 12x148mm / Tapered Headtube / Internal Cable Routing
Fork	RockShox Judy Silver TK Solo Air / 100mm travel
Rear Derailleur	Shimano Deore RD-M6100 SGS Shadow Plus / 12 Speed
Shifters	Shimano Deore SL-M6100-R / 12 Speed
Crankset	Shimano FC-MT511-1, 32T
Cassette	Shimano Deore CS-M6100-12 / 10-51 T
Wheelset	Syncros / 32H
Tires	Schwalbe Rapid Rob 29x2.25" / Active line
Handlebar	Syncros Alloy 6061, T shape Flat / 9° / 740mm
Seatpost	Syncros / 31.6mm
H'stem	Syncros Alloy 6061 31.8mm
Headset	Syncros OE Press Fit / Tapered 1.5"-1 1/8"
Hub (Front)	Formula CL-811 / 15x100mm
Hub (Rear)	Boost 12x148mm
