SCOTT SCALE 950 User Manual

2023 SCALE | ENGLISH 6
|
SCALE
SCALE
RIDELOC
SCALE RC FORK PART NO. DROPPER
SCALE RC SL 3P/0-7-14MM 296245 NO
SCALE RC WORLD CUP EVO 3P/0-7-14MM 296245 NO
SCALE WORLD CUP 3P/0-7-14MM 296245 NO
SCALE RC TEAM ISSUE 2P/0-10MM 296245 NO
SCALE RC TEAM 2P/0-10MM 296245 NO
SCALE FORK PART NO. DROPPER
SCALE 910 3P/0-7-14MM 296245 NO
SCALE 920 3P/0-7-14MM 296245 NO
SCALE 925 3P/0-7-14MM 296245 NO
SCALE 930 3P/0-7-14MM 296245 NO
SCALE 940 2P/0-17MM 296246 NO
SCALE 950 3P/0-7-14MM 296245 NO
SCALE 960 3P/0-7-14MM 296245 NO
SCALE 965 2P/0-17MM 230099 NO
CONTESSA SCALE FORK PART NO. DROPPER
CONTESSA SCALE 910 3P/0-7-14MM 296245 NO
CONTESSA SCALE 920 2P/0-17MM 296246 NO
CONTESSA SCALE 930 2P/0-17MM 230099 NO
There are two Rideloc levers for the Scale, this will depend on which fork has been fitted.
296245 SCO RIDELOC DOWNCLAMP 0-7-14/0-10MM 23
296246 SCO RIDELOC DOWNCLAMP 2P/0-17MM 23

SCOTT SCALE 950 Specifications

General

Brakes	Shimano MT201 Disc
Chain	KMC X12
Saddle	Syncros Belcarra Regular 2.5
Rotor	Shimano SM-RT10 CL / 180/F and 160/R
Spokes	Stainless Black 15G / 1.8mm
Frame	Boost 12x148mm / Tapered Headtube / Internal Cable Routing
Fork	RockShox Judy Silver TK Solo Air / 100mm travel
Rear Derailleur	Shimano Deore RD-M6100 SGS Shadow Plus / 12 Speed
Shifters	Shimano Deore SL-M6100-R / 12 Speed
Crankset	Shimano FC-MT511-1, 32T
Cassette	Shimano Deore CS-M6100-12 / 10-51 T
Wheelset	Syncros / 32H
Tires	Schwalbe Rapid Rob 29x2.25" / Active line
Handlebar	Syncros Alloy 6061, T shape Flat / 9° / 740mm
Seatpost	Syncros / 31.6mm
H'stem	Syncros Alloy 6061 31.8mm
Headset	Syncros OE Press Fit / Tapered 1.5"-1 1/8"
Hub (Front)	Formula CL-811 / 15x100mm
Hub (Rear)	Boost 12x148mm
