SCOTT Scale User Manual

WWW.SCOTT-SPORTS.COM
ENGLISHENGLISH
Scale Concept . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 04
Geometry/Technical Data Scale . . . . . . . . . . . . . . . . . . . . . . . . . 04
BB Standards/FD Mounting Details . . . . . . . . . . . . . . . . . . . . . . . 06
Chainguide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 06
Headset Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .07
BB Cable Guide/Cable Routing . . . . . . . . . . . . . . . . . . . . . . . . . 08
Seattube Clamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Replaceable Rear Derailleur Hanger . . . . . . . . . . . . . . . . . . . . . . . 10
Rear Disc Brake Mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Front Fork Set-Up/Change of Front Fork . . . . . . . . . . . . . . . . . . . . 11
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
•
CONTENTS
The Scale bikes should be adjusted exactly to the current rider to
maximize safety, comfort and fun while riding.
All adjustments should be done at your local SCOTT dealer or by
following the instructions in this manual.
Please contact your authorized SCOTT dealer if you have any
doubts or require further information in order to avoid technical
problems or any harm.
03 |
2016 BIKE USER MANUAL | SCALESCALE | 2016 BIKE USER MANUAL
| 02

SCOTT Scale Specifications

General

Fork	Suntour XCR32-RL-R / Coil Spring Remote Lockout / Reb. Adj. 100mm travel
Wheel Size	29"
Brakes	Shimano MT200 Disc
Seatpost	Syncros
Seat	Syncros
Headset	Syncros
Rims	Syncros
Front Tire	Schwalbe
Rear Tire	Schwalbe
