ENGLISHENGLISH
Ritchey WCS Carbon Zero Tapered PF 50-61mm 18mm UD PRD 13636
Ritchey PRO Tapered PF 50-61mm 12.9mm PRD 13640
It is also possible to use forks with a standard 1 1/8” steerer tube when using a reducer
headset such as e.g.
Ritchey WCS Carbon Zero Tapered PF 50-61mm 18mm UD for 1 1/18" fork PRD 14860
•
BB CABLE GUIDE/CABLE ROUTING
Scale features also an internal cable routing for front and rear derailleur.
A special BB Cable Guide was developed for Scale which is available as a spare part at the
SCOTT distribution with article number
for Scale 700
235285 Cableguide BB Scale 700 2014
and for Scale 900
219579 Cableguide BB Scale
Please note that those 2 cableguides are not interchangeable between the frame sizes.
Please note that the outer housing of the FD and RD cables will stop at the cable stop/port
on the front end of the down tube.
If you want to replace the cables, please follow these steps:
1. Remove the clip-in BB Guide in the BB housing
2. Push the inner cables from the front downward inside the downtube to the BB housing.
3. Pull them out of the related holes (RD on right side, FD on left side) on the BB housing.
4. Push them through the related holes on the BB Guide and clip the BB Guide into the
BB housing
5. Follow the standard set up and assembly instructions of the shifting system manufacturer
for final adjustment of the shifting system
