SCS Sentinel Open3 - Page 64

EN ::: 22
EN
b
- Remove the rack
c
- Drill the gate at the top of the marks
for the  xing holes.
(
fastening 4)
d
- Screw the rack to the gate. In order
to respect the necessary gap between
rack and pinion raise the rack slightly
when attaching.
In this way you can obtain the desired
gap between the two elements.
(fastening 5)
Tracé
Cr
ay
on
Cr
a
yon
Tracé
Perçage à
effectuer
Ne jamais
perçer en bas
Haut
Bas
(fastening 4)
Perçage
1.5 à 2 mm
(fastening 5)
motor
pinion
DRILL
DRAWING
maintain the
level device
DRAWING DRAWING
TOP
BOTTOM
don’t drill in
bottom
drill
drill
