B Option
Magnetic Bond Sensor
NO - SPST
D Option
Door Status Sensor
12 or 24 VDC
NOT USED
CLOSED - NO
COM
OPEN - NC
Cradle
Position Posts
PC Board
+
3
4
5
6
Input module wiring.7
Remove cover plate screws.
1 2
Remove cover plate.
3
6
Lift input module
and magnetic coil
from the case.
Place input module vertically between post
a
t each side of case.
Remove 1 screw
from the case
bottom.
Place the
Magnetic Bond
Sensor at the
base of the
Magnetic Core.
Secure sensor
in place with
screw as
shown.
5
The Magnetic Bond Sensor should
be positioned as shown
below, after step 4.
+
3
4
5
6
+
3
4
5
6
+
3
4
5
6
7
8
EZ-B-80 MAGNETIC BOND SENSOR
Modular Kit
B Option
Magnetic Bond Sensor
NO - SPST
Magnetic Core
Connector
D Option
Door Status Sensor
12 or 24 VDC
NOT USED
CLOSED - NO
COM
OPEN - NC
Cradle
Position Posts
PC Board
+
3
4
5
6
Input module wiring.7
Remove cover plate screws.
2
Remove cover plate.
3
6
Lift input module
and magnetic coil
from the case.
Place input module vertically between post
a
t each side of case.
Remove 1 screw
from the case
bottom.
Place the
Magnetic Bond
Sensor at the
base of the
Magnetic Core.
Secure sensor
in place with
screw as
shown.
The Magnetic Bond Sensor should
b
e positioned as shown
below, after step 4.
+
3
4
5
6
+
3
4
5
6
+
3
4
5
6
7
8
B Option
Magnetic Bond Sensor
NO - SPST
Magnetic Core
Connector
D Option
Door Status Sensor
12 or 24 VDC
NOT USED
CLOSED - NO
COM
OPEN - NC
Cradle
Position Posts
PC Board
Input module wiring.7
Remove cover plate screws.
2
Remove cover plate.
3
6
Lift input module
and magnetic coil
from the case.
Place input module vertically between post
a
t each side of case.
Remove 1 screw
from the case
bottom.
Place the
Magnetic Bond
Sensor at the
base of the
Magnetic Core.
Secure sensor
in place with
screw as
shown.
The Magnetic Bond Sensor should
b
e positioned as shown
below, after step 4.
+
3
4
5
6
+
3
4
5
6
7
8
4
Place input module vertically between post
at each side of case.
Remove 1 screw
from the case
bottom.
Place the
Magnetic Bond
Sensor at the
base of the
Magnetic Core.
Secure sensor
in place with
screw as
shown.
8
Attach cover plate.
Cradle
Position Posts
PC Board
+
3
4
5
6
Remove cover plate screws.
1 2
Remove cover plate.
6
Place input module vertically between post
at each side of case.
Remove 1 screw
from the case
bottom.
Place the
Magnetic Bond
Sensor at the
base of the
Magnetic Core.
Secure sensor
in place with
screw as
shown.
5
The Magnetic Bond Sensor should
be positioned as shown
below, after step 4.
+
3
4
5
6
+
3
4
5
6
7
8
Cradle
Position Posts
PC Board
+
3
4
5
6
Remove cover plate screws.
1 2
Remove cover plate.
6
Place input module vertically between post
at each side of case.
Remove 1 screw
from the case
bottom.
Place the
Magnetic Bond
Sensor at the
base of the
Magnetic Core.
Secure sensor
in place with
screw as
shown.
5
The Magnetic Bond Sensor should
be positioned as shown
below, after step 4.
+
3
4
5
6
+
3
4
5
6
7
8
B Option
Magnetic Bond Sensor
NO - SPST
Magnetic Core
Connector
D Option
Door Status Sensor
12 or 24 VDC
NOT USED
CLOSED - NO
COM
OPEN - NC
Input module wiring.7
3
Lift input module
and magnetic coil
from the case.
4
Place input module vertically between post
at each side of case.
Remove 1 screw
from the case
bottom.
Place the
Magnetic Bond
Sensor at the
base of the
Magnetic Core.
Secure sensor
in place with
screw as
shown.
8
Attach cover plate.
+
3
4
5
6
B Option
Magnetic Bond Sensor
NO - SPST
Magnetic Core
Connector
D Option
Door Status Sensor
12 or 24 VDC
NOT USED
CLOSED - NO
COM
OPEN - NC
Input module wiring.
Lift input module
a
nd magnetic coil
from the case.
4
Place input module vertically between post
at each side of case.
Remove 1 screw
from the case
bottom.
Place the
Magnetic Bond
Sensor at the
base of the
Magnetic Core.
Secure sensor
in place with
screw as
shown.
8
Attach cover plate.
+
3
4
5
6
While a Door Status Sensor indicates the door is open
or closed, SDC’s Magnetic Bond Sensor provides higher
security monitoring by indicating the locked / unlocked
mode, tampering and low holding force. The use of
both the door status and magnetic bond sensor is
recommended for high security applications.
Application: Lock secure status annunciation,
mantrap system logic,
CCTV camera activation.
Output: SPDT Dry Contact,
250 mA @ 12/24VDC
Specify 2 for 1582
