SDMO PERFORM 7500 T - Page 24

11. Cable sizes
Laying mode = cables on cable tray or racks not perforated / admissible voltage drop = 5% / Multiconductors.
Cable type PVC 70°C (example H07RNF) / Ambient temperature =30°C.
Rated Current (A)
Cable lengths
0 to 50m 51 to 100m 101 to 150m
mm² / AWG mm² / AWG mm² / AWG
Single-phase Three-phase Single-phase Three-phase Single-phase Three-phase
10 4 / 10 1.5 / 14 10 / 7 2.5 / 12 10 / 7 4 / 10
16 6 / 9 2.5 / 12 10 / 7 4 / 10 16 / 5 6 / 9
20 10 / 7 2.5 / 12 16 / 5 4 / 10 25 / 3 6 / 9
25 10 / 7 4 / 10 16 / 5 6 / 9 25 / 3 10 / 7
32 10 / 7
25 / 3 35 / 2
40 16 / 5 35 / 2 50 / 0
50 16 / 5 35 / 2 50 / 0
63 25 / 3 50 / 0 70 / 2 / 0
12. EC Declaration of conformity
Name and address of manufacturer :
SDMO Industries - 12 bis rue de la Villeneuve - CS 92848 -
29228 BREST Cedex 2 – France.
Name and address of the person authorised to create and keep
the technical file
G. Le Gall - SDMO Industries - 12 bis rue de la Villeneuve -
CS 92848 - 29228 BREST Cedex 2 – France.
Product description : Make : Type : Serial numbers:
Generating set SDMO
PERFORM 7500 T
3499231000038
01-2011-00000000-000
> 52-2014-99999999-999
G. Le Gall, the manufacturer's authorised representative, hereby declares that the product conforms to the following EU Directives:
2006/42/EC Machinery Directive ; 2006/95/EC Low Voltage Directive ; 2004/108/EC Directive on Electromagnetic Compatibility ;
2000/14/EC Directive relating to the Noise Emission of Outdoor Equipment.
For the directive 2000/14/EC :
Notified body :
Compliance
procedure :
Measured
sound power level:
Guaranteed
sound power level
(LwA) :
Rated output :
CETIM - BP 67- F60304 -
SENLIS
Appendix VI. 96,79 dB(A) 97 dB(A) 5200 W
Brest, 01/12/2011
G. Le Gall, Engineering Director.
13. Serial numbers
Serial numbers shall be requested for technical assistance or when ordering spare parts.
Please indicate the generating set and engine numbers below.
Generating set serial number: ……../………….. - ……..……..….…. - ………
(E.g. "No.: 45/2007 – 39645109 – 001")
(indicated on the identification plate of the generating set affixed inside one of the two bands or to the frame.)
Engine brand: ………………………………………..
Engine serial number: ………………………………………..
(E.g. Kohler "SERIAL NO. 4001200908")
