11. Cable sizes
Laying mode = cables on cable tray or racks not perforated / admissible voltage drop = 5% / Multiconductors.
Cable type PVC 70°C (example H07RNF) / Ambient temperature =30°C.
Rated Current (A)
Cable lengths
0 to 50m
51 to 100m
101 to 150m
mm² / AWG
mm² / AWG
mm² / AWG
Single-phase
Three-phase
Single-phase
Three-phase
Single-phase
Three-phase
10
4 / 10
1.5 / 14
10 / 7
2.5 / 12
10 / 7
4 / 10
16
6 / 9
2.5 / 12
10 / 7
4 / 10
16 / 5
6 / 9
20
10 / 7
2.5 / 12
16 / 5
4 / 10
25 / 3
6 / 9
25
10 / 7
4 / 10
16 / 5
6 / 9
25 / 3
10 / 7
32
10 / 7
25 / 3
35 / 2
40
16 / 5
35 / 2
50 / 0
50
16 / 5
35 / 2
50 / 0
63
25 / 3
50 / 0
70 / 2 / 0
12. EC Declaration of conformity
Name and address of manufacturer
: SDMO Industries, 12 bis rue de la Villeneuve, CS 92848, 29228 BREST CEDEX 2, FRANCE
Description of the equipment
Generating set
Make
SDMO
Type
TECH7500TE-AVR - TECHNIC 7500 TE AVR C
TECH7500TE-AVR-R5T - TECHNIC 7500 TE AVR C R03B R05A
TECH9000TE - TECHNIC 9000 TE C
TECH9000TE-R05ATT - TECHNIC 9000 TE
Name and address of the person authorised to create and keep the technical file
G. Le Gall, SDMO, 12 bis rue de la Villeneuve, CS 92848, 29228 BREST CEDEX 2, FRANCE
G. Le Gall, the manufacturer's authorised representative, hereby declares that the equipment, if installed inside soundproofed
premises(*), complies with the following EU Directives:
2006/42/EC / Machinery Directive.
2006/95/EC / Low Voltage Directive.
2004/108/EC / Directive on Electromagnetic Compatibility.
(*) In this instance, Directive 2000/14/EC dated 08/05/2000 relating to noise
emission in the environment by equipment for use outdoors is not applicable. This
equipment must be installed in compliance with safety regulations by an approved
professional (consult us).
02/2011 - G. Le Gall
13. Serial numbers
Serial numbers shall be requested for technical assistance or when ordering spare parts.
Please indicate the generating set and engine numbers below.
Generating set serial number: ……έέή…………έέΝ- ……έέ……έέ…έ…έΝ- ………
(E.g. "No.: 45/2007 – 39645109 – 001")
(indicated on the identification plate of the generating set affixed inside one of the two bands or to the frame.)
Engine brand: ………………………………………έέ
Engine serial number: ………………………………………έέ
(E.g. Kohler "SERIAL NO. 4001200908")
