SE Controls OS2 User Manual

2
1.0 Introduction
The OS2 AC Controller is a 230V AC control unit designed for use with 3-wire 230V AC actuators and
magnets in a natural ventilation system.
Brief device details:
Power
Class 1
Input supply 230V AC 50/60 Hz from a 6A fused un switched spur
Current Rating 6A
Output 230V AC Single Channel
Other Real time clock battery (support life 10 Years)
Environment
IP Rating: IP20
Humidity Range 10 to 90% Non-Condensing
Storage -20 to + 75°C
Operating temp -10 to +50°C
Miscellaneous
Part Number FCS 0021 0001
Dimensions 220x 209x 124mm
Weight 1.2kg (approx)

SE Controls OS2 Specifications

General

Brand	SE Controls
Model	OS2
Category	Controller
Language	English
