Please note that the controller enclosure is rated at IP20 and so should not be mounted:
• In damp or wet locations
• Where there is likely to be significant amounts of dust.
• In areas classified as having a potentially explosive atmosphere.
At this point it is recommended that the required number of cable entry glands is checked and any additional
knock-outs required to achieve this are removed from the end of the controller. The required number of
Ø20mm end mounted cable glands can then be fitted.
4.0 Installation Notes
It is advisable to strip the outer sheath of signal cables back to the entry point into the enclosure bearing in
mind to leave enough to provide mechanical protection for cable movement over time. Inner cores can be
dressed under the edges of the power and control board providing a neater and more ordered solution. When
stripping inner cores, only strip enough for a good electromechanical contact with terminal blocks.
