SE Electronics Z5600a II - Technical Specifications

4
Technical Specifications
Capsule
Handcrafted 1” diaphragm true condenser capsule
Polar patterns
9 (omni, cardioid, figure-8 with three additional steps between each)
Frequency range
20 – 20,000 Hz
Sensitivity
25 mV/Pa (-32 dBV)
Attenuation pad
10 dB, switchable
Max. SPL (0.5% THD)
127 / 137 dB
SPL
(0/10 dB Attenuation pad)
Equivalent noise level
13 dB(A)
Dynamic Range
114 / 124 dB (0/10 dB Attenuation pad)
Signal-to-noise ratio
81 dB
Low cut filter
50 Hz, 6 dB/Oct, switchable
Electrical impedance
200 Ohms
Recommended load impedance
>2k Ohms
Connectivity
3-pin male XLR connector
Dimensions
Microphone:
Diameter: 62 mm (2.44 in.) Length: 220 mm (8.66 in.)
Power Supply Unit:
186 x 157 x 81 mm (7.32 x 6.18 x 3.19 in.)
Weight
Microphone:
850 g (30.0 oz.)
Power Supply Unit:
1970 g (69.5 oz.)
Cardioid
Hypercardioid






 
 






 






































 
 






 

































































 
 





 







































 
 





 






