EQUIPMENT
lmo2008-006-016_a
230 CHALLENGER/SE
1. Latch handle
lmo2012-005-003_a
230 CHALLENGER SP/230 WAKE
1. Latch handle
To release latch, pull and turn latch han-
dle. Turning the latch handle locks it in
position. Lift storage compartment
cover, the gas assist cylinder will com-
plete the opening and hold the cover
open.
lmo2007-003-039_c
TYPICAL
Step 1: Pull
Step 2: Turn
1. Latch handle
Unlock the latch handle before closing
cover.
NOTICE
Never leave any heavy
or breakable objects in the storage
compartment. Never operate the
boat with the rear storage compart-
ment cover opened or unlocked.
WARNING
Always ensure rear storage com-
partment lid is closed and securely
locked before trailering.
Storage Tray
NOTICE
In order to avoid damage,
MAXIMUM LOAD on storage tray
must not exceed 22.5 kg (50 lb).
The storage tray is removable, allow-
ing access to the engine compartment.
Grab the handles and lift in a upward
movement.
WARNING
Whenstoragetrayisliftedorre-
moved, never touch any electri-
cal part when starting engines or
while in operation. Never leave
any object, rag, tool, etc., in the en-
gine compartment or in the bilge.
Ensure latch cable is returned to the
locking position, then firmly close stor-
age compartment cover to re-latch.
10) Grab Handles
Grab handles provide a handhold for
the passengers.
Although grab handles are provided,
never perform maneuvers that place a
passenger or the driver at risk for being
ejected or thrown out of their seat.
NOTICE
Never use the grab han-
dles to pull anything or to lift t
he
boat.
Refer to components location illustra-
tions at the beginning of this section
forgrabhandlelocations.
_______________
75
