5
Now slide the swivel seat(s) into the quick release swivel
seat mounts and make sure that the spring loaded lever
mechanisms lock in place.
Optional Pedestal for Swivel Seat
The Pedestal comes with four bolts and nuts to attach it to
the Swivel Seat.
Bolt the upper end of the pedestal to the swivel seat as
shown above. And then slide the other end of the pedestal
into the quick release swivel seat mounts and make sure
that the spring loaded lever mechanisms locks in
place.
Please note, for
disassembly it is very
easy to detach the
swivel seat or the
pedestal from the
quick release
seatmount by sliding
them out while lifting
up the spring loaded
quick release lever mechanism on the swivel seat mount
with your finger as shown below.
Rod Holders
Each rod holder includes the plastic flush mount adapter
and hardware as shown below.
Please note, the SE 375
Deluxe Package
includes 2 rod holders
and the Pro Angler’s
Package includes 4 rod
holders. The SE 440
Deluxe Package
includes 4 rod holders
and 6 rod holders in the Pro Angler’s Package.
Attach the flush mount adapters for rod holders at the
ends of the 3rd rearmost aluminum bench and/or the first
aluminum bench from the bow. Each of these ends on the
aluminum aluminum benches have 1 big 1 1/2" hole & 4
1/8” holes surrounding the big hole as shown below.
Use four 3/4” screws to
attach each flush mount
adapter to the aluminum
bench with a phillips
head screw driver.
Please note, the
adapters can stay
attached to the
aluminum benches and
never need to be
disassembled.
