SEA Field - Mechanical Installation: Product Overview; Gate Arrangement Pre-checks

118,1 inches
FIELD is an high quality electromechanical in-ground operator
for residential use for swing gates with a leaf lenght of 137,8
inches and weight leaf of 1322,8
Lubrication with grease (oil bath optional)
Available in 3 versions: slow, fast and also with low voltage
(24V) for maximum safety and intensive use.
Electronic limit switch and mecanichal stop in the carrying box.
Adjustable slow down in opening and closing with GATE
control Board.
Lbs.
1 Handle bar device
2 Electric motor
3 Cover fixation screw
4 Leaf device
5 Counter-connecting rod
120V (60 Hz)
280W
From -4°F to 131°F
110° - 180° (optional)
3R Type
300 Nm
1322,8 Lbs
6 Foundation carrying box
7 Hole for water discharge
8 Hole electric cable exit
9 Adjustable limit switch in closing
10 Adjustable limit switch in opening
MAIN PARTS NOMENCLATURE
1. GATE ARRANGEMENT
You must do some checks on the gate to see if fitting a FIELD
system is possible:
A. (Make sure that) the fixed and moving parts of the gate are
strong and non-deformable;
B. the weight of each gate leaf must not exceed 1322,8 Lbs
(Field Oil/Field Oil 24V) ;
C. the hinges and general structure must be in good condition
and the gate must move smoothly throughout its travel;
D. the upper hinge alone is sufficient to install the unit; those
which are unnecessary can be eliminated (the lower and that
in the middle if exists);
E. in case of leaf length superior of 70,9 inches and 330,7Lbs
of weight, it is recommended to fix to the ground a mechanical
stop in closing (Fig. 3).
DIMENSIONS (inches)
Power supply
Absorbed Power
Frequency of use
Operating temperature
Weight
Max leaf width
Opening degree
Time of 90° movement
Protection class
Starting capacitor
Max torque
Max leaf weight
78,7 inches
137,8 inches
1322,8 Lbs
661,4 Lbs
Max leaf weight Max leaf lenght
GRAPHIC FOR THE USE OF
FIELD AND FIELD 24V
Fig. 2
1
2,7
2,5
1,8
FIELD
OIL
FIELD
OIL 24V
20 cycles/h
27,5 Lbs
137,8 inc.
18 s.
35 uF
50 cycles/h
28,7 Lbs
118,1 inc.
14/30 s.
-
992,1 Lbs
11
22
33
44
55
66
77
88
1010
Fig. 1
99
6,9
16
,
1
International registered trademark n. 2.777.971
MECHANICAL INSTALLATION
FIELD OIL
FIELD OIL 24V
FIELD OIL
FIELD OIL 24V
FIELD
67410825
TECHNICAL DATA
130W
Rev.04 - 02/2016
5
