STS11 Touchscreen Pro
g
rammable Thermostat
4. Align the screw blocks with the pins on the
back of the thermostat.
5. Push the thermostat straight onto the
wallplate until it snaps into place.
72
BATTERIES(2)
-+-+
PINS ON BACK OF
THERMOSTAT
WALLPLATE
TERMINAL SCREW BLOCK
STS11 Touchscreen Pro
g
rammable Thermostat
Batter
y
Tips
1. Replace the batteries as soon as “Batt”
flashes in the display. The Battery indicato
r
flashes in the display one month before the
batteries run down completely.
2. Always use fresh AA alkaline batteries.
Non-alkaline batteries do not last as long
and can leak, causing thermostat damage.
3. Although the thermostat has a Low
Battery indicator, replace the batteries
once a year to prevent the thermostat and
heating/cooling system from shutting down
due to lack of battery power.
Screen Locks
Partiall
y
Locked Screen
When partially locked, the screen indicates
Screen Locked for 5 to 7 seconds whenever th
e
user attempts to press a key that is locked.
Pressing a locked key, while Screen Locked is
shown, flashes “
Screen Lo cked ” on the
screen.
In this mode, all keys are locked except the
Temperature Up and Down arrow keys:
User can change temperature up or down
but cannot change schedule settings.
Temporary temperature change lasts until
next scheduled period and that time shows
on screen.
To cancel temperature override and begin
following schedule, press CANCEL key.
To unlock screen, see Installer Setup section.
Fully Locked Screen
In this mode, all keys are locked and not
functional. To unlock screen, see Installer
Setup section. The screen continuously
displays Screen Locked.
73
SCREEN
LOCKED
PM
TUE
Room
Running As SCHED
Set To
SYSTEM
HEAT
MORE
SCHED HOLD CLOCK
SCREEN
AUTO
FAN
