Figure 4 – Connecting the Snack, Beverage & Entrée Units
Figure 5 – Connecting the Snack, Beverage & Entrée Units
LOADING PRODUCT TRAYS
Open the front door of vendor, and lift up the plastic lock lever on the right side of the tray to unlock.
Holding the lever up, grasp the tray and lift the front of the tray slightly and pull forward. The tray will
slide out and then tilt down to make loading of products easier. Load only one product tray at a time
(See Figure 6).
Plug both black
power cords
into wall outlets
Insert the entrée
main harness into
the opening
located in the rear
of the Snack unit.
