1.0 Introduction
This manual describes the functional, mechanical and interface specifications for the following:
Seagate® Exos™ X14 SATA drive models.
These drives provide the following key features:
 256 MB data buffer.
 7200 RPM spindle speed.
 Full-track multiple-sector transfer capability without local processor intervention.
 High instantaneous (burst) data-transfer rates (up to 600MB per second).
 Native Command Queuing with command ordering to increase performance in demanding applications.
 PowerChoice™ for selectable power savings
 Perpendicular recording technology provides the drives with increased areal density.
 SeaTools™ diagnostic software performs a drive self-test that eliminates unnecessary drive returns.
 State-of-the-art cache and on-the-fly error-correction algorithms.
 Support for S.M.A.R.T. drive monitoring and reporting.
 Supports latching SATA cables and connectors.
 T13 Fast Format conversion (see Section 2.2.1)
 Top Cover Attached motor for excellent vibration tolerance
 Worldwide Name (WWN) capability uniquely identifies the drive.
NOTE Seagate recommends validating the configuration with the selected HBA/RAID
controller manufacturer to ensure use of full capacity is supported.
NOTE Previous generations of Seagate Self-Encrypting Drive models were called Full Disk
Encryption (FDE) models before a differentiation between drive-based encryption
and other forms of encryption was necessary.
NOTE The Self-Encrypting Drive models indicated on the cover of this product manual
have provisions for “Security of Data at Rest” based on the standards defined by the
Trusted Computing Group (see www.trustedcomputinggroup.org).
Table 1: Models
Standard 512E models SED 512E models
ST14000NM0018
ST12000NM0008
ST10000NM0478
ST14000NM0258
ST12000NM0248
ST10000NM0568
