OPERATION
MANUAL
Product:
Document #:
Rev:
Page:
SEAKEEPER 5 GYRO
90246
4
2 of 13
Section 2: SYSTEM OPERATION
a. HOME Screen BUTTON ICON function
i. GYRO ON/OFF and FAULT RESET
1. The ICON will change from red (GYRO OFF) to green (GYRO ON)
2. The ICON will turn red indicating the GYRO is off when a fault
appears
3. When a FAULT occurs the BUTTON is used to reset the active fault
ii. GYRO LOCK/UNLOCK
1. When the GYRO control is initializing, or the GYRO off, the lock
symbols will both be blue
2. When the GYRO is in LOCK mode, stabilization is off, the LOCK
symbol will be red
3. When the GYRO is UNLOCK, stabilization is on, the UNLOCK symbol
will be green
iii. DISPLAY DAY/NIGHT
1. Toggles the DISPLAY brightness between the Day and Night settings
