Seakeeper 5 GYRO - 90246-REV 4 SEAKEEPER 5 OPERATION MANUAL SECTION 6 GYRO SPECS 02.10.2015; Seakeeper 5 Gyro Specifications & Summary

OPERATION
MANUAL
Product:
Document #:
Rev:
Page:
SEAKEEPER 5 GYRO
90246
4
1 of 3
Section 6: GYRO SPECIFICATIONS
Seakeeper 5 Gyro Specifications & Summary
Rated RPM
10,700 RPM
Angular Momentum at Rated RPM
5,000 N-M-S
Anti-Rolling Torque at Rated RPM
13,089 N-M
Spool-up Time to Rated Speed (10,700 RPM)
50 minutes
Spool-up Time to Stabilization (9,035 RPM)
35 minutes
Spool-up Power
AC Motor
DC Control
2000 Watts Max
180 Watts
Operating Power
AC Motor (Sea state dependent)
DC Control
1500-2000 Watts
180 Watts
Voltage
AC Input
DC Input
110-230 VAC (±10%), 50/60 Hz, Single Phase
12 VDC @ 15 Amps
Sea Water Supply to Heat Exchanger
30 LPM (8 GPM) maximum
15 LPM (4 GPM) minimum
Ambient Air Temperature
0⁰ - 60⁰ C (32⁰ - 140⁰ F)
Weight
358 kg. (790 lbs.) bolt-in installation
Envelope Dimensions
0.765 long x 0.757 wide x 0..628 high (meters)
30.1 long x 29.8 wide x 24.7 high (inches)
Noise Output
Steady state noise measured in the factory at a
1 meter distance measures 70 – 72 dBC.
