FT430/440/450 INSTRUCTIONS

Seametrics • 253.872.0284 Page 11 seametrics.com

CONNECTION DIAGRAMS

FT4XX Sensus Tranceiver Connections

FT4XX Eqipped with Sensus Board (Side View)

Sensus Tranceiver

Red (Power/Clock)

Black (Ground)

Green (Data)

Red

Black

Green

NOTE: A Sensus 2m (6 ft) output cable is prewired to the

Seametrics product at the factory. Longer cables are optional.
