DC Power Steering System
11
DC POWER STEERING UNIT
POWER STEERING CYINDER
SEASTAR
H
ELM PUMP
P
R
R
S
AUTOPILOT
PUMP
HB
TNK
HP
PRS
HS
HT
H1
H2
D
C
P
O
W
E
R
U
N
I
T
PRS
C1
C2
TNK
1/2" DASH 8 2000psi SAE 100R
SEASTAR OUTBOARD STEERING
HOSES AND/OR COPPER TUBING
Figure 10. Typical Plumbing Schematic.
NOTICE
The drawing in figure 10 is used for visual purposes ONLY, refer to
page 9 to page 10 for your specific plumbing details.
