Seat MO - Maintenance

35
Battery pack
EN
Battery and charger specifications
Battery specifications
Nominal charge 5.6 kWh
Chemistry of the cells Lithium-ion cells
Weight 41kg
Height unfolded 870mm
Housing height 270mm
Wheel width 330mm
Housing depth 440mm
Nominal voltage of the battery 51VDC
Storage temperature without charging -4°F (-20°C) to 176°F (80°C) max.
Operating temperature
32°F (0°C) to 122°F (50°C) (charging)
14°F (–10°C) to 140°F (60°C) (discharging)
Housing material Aluminium and polycarbonate PC
Maximum charge power 35A
Maximum discharge power 250A
Charger type Onboard 90-240 VAC; 600 W
Standard charge time 6-8h
Modes Eco City Sport
Maximum driving distance
85 miles
(137km)
65 miles
(104km)
51 miles
(82km)
Fig. 35 Battery dimensions
870
410
450
330
