Seat MO - Basic components

6
Basic components
Basic components
Fig. 1 Basic components
3
1
11
2
13
12
5
4
7
9
10
8
6
The basic components (from a user stand-
point) that make up the eScooter are:
1
Mirror ››› page11
2
Front mudguard
3
Front wheel
4
Instrument panel ››› page15
5
Electric socket – USB
6
Seat ››› page26
7
Carry hook
8
Battery ››› page28
9
Side stand ››› page27
10
Central stand ››› page27
11
Ignition ››› page24
12
Brake light, indicators
13
Motor (rear wheel) ››› page27
