PrimeTest Series
PG 2 SEAWARD
QUICK START GUIDE
TESTED. TRUSTED… WORLDWIDE. PG 3
The PrimeTest Series must not be connected to electric circuits with
nominal voltage greater than 300 V AC/DC CAT II.
The tester and all associated cables and leads must be checked for
signs of damage before equipment is operated.
The PrimeTest Series is intended for use in a dry environment only.
Do not touch the bare tip of the test probes.
WARNING - READ BEFORE FIRST USE
Warning of electrical danger! Indicates instructions must be followed to
avoid danger to persons.
Important, follow the documentation! This symbol indicates that the
operating instructions must be adhered to in order to avoid danger.
The PrimeTest Series must only be used by adequately trained personnel. To ensure
safe operation of the unit, all notes and warnings in these instructions must be
observed at all times.
Where safe operation of the tester is no longer possible it should be immediately shut
down and secured to prevent accidental operation.
It must be assumed that safe operation is no longer possible:
• if the instrument or leads show visible signs of damage or
• the instrument does not function or
• after long periods of storage under adverse environmental conditions.
GETTING TO KNOW YOUR PRIMETEST
1. Test Terminals
2. Screen
3. Function Keys F1 - F5
4. QWERTY Keyboard
5. Power Off / Stop Key
6. Power On / Start Key
7. Arrow Keys
8. EUT Socket
9. IEC Inlet
10. Probe Socket 1
11. Mains Inlet / Probe Socket 2
12. USB B Port
13. USB Flash Drive Port (Elite+ only)
14. Flash (Elite+ only)
15. Camera (Elite+ only)
16. Battery Cover
1.
6.
2.
7.
3.
8.
4.
9.
5.
10.
11.
12. 13.
14. 15.
16.
