SEB RGDAT-A70 User Manual

Pin number
Signal name
Notes
9
+VALIM
Reverse signal digital input (common)
10
-VALIM
Power supply input (GND 24V)
The following figure shows the layout of the electronic board, with indication of where terminal blocks
MA and MB are placed, and relative pin numbering.
Connector to remote control system
The following figure shows the design of the connector to the remote control system.
P515D851 Rev. E November 2019 Pag. 16 of 45
