SEFA
®
France
Page N°12
IX. SERVICE
USE BY QUALIFIED STAFF ONLY
ANY MAINTENANCE INTERVENTION MUST BE DONE WHEN THE MACHINE IS
OFF AND LOCKED
(ELECTRIC AND PNEUMATIC ENERGIES UNPLUGGED)
It is recommended to have the following tools within reach:
- Cruciform and flat screwdrivers
- A set of end wrenches and box spanners
- Small adjustable pliers
- Circlip pliers
- Long and fine pliers with insulating handle
- A set of Allen key
- A multimeter
Before any handling, check that the temperature of the heating plate is lower than 25°C on
the display unit.
1. PARTS SUBJECTED TO WEAR AND TEAR
On any order:
precise the specification, the reference and the quantity
Reference
Specification
Quantity
ELECTRIC EQUIPMENT
CAR-X1 CONTROL CARD XTRA 1
ECR-466 FRONT SCREEN VERS.50°C BACKLIT 1
CLA-371 6-KEY KEYBOARD 1
RES-548 HEAT ELEMENT MICA 450X380 2250 WATT 1
FUS-153 FUSE 5x20mmT 16 A 250V 2
CARD FUSE 80mAT 250V 1
COM-355 COMBI SWITCH 1
SON-188 T° SENSOR 1
CON-120 ON CONTACT 2
To Next Page
