SEFA
®
France
Page N°7
2. INSTALLATION
USE BY QUALIFIED STAFF ONLY
Do not manipulate the machine by the plates!
Unpack the machine.
Place it on a stable table handling it by its frame.
After having properly positioned the machine on it working place :
• Electrically plug the press in with the provided plug (220 Volt + Earth / 50 or 60 Hertz),
• Pneumatically connect the press to your compressed air network (3 bar mini, 10 bar maxi).
3. DESCRIPTION OF THE RUNNING CYCLE
1. The operator will have to power up the machine using the main switch which is on the back of the
machine,
2. Check if the screen lights on. After a welcome message, it will indicate the values preset in the
workshop,
3. Set the temperature thanks to the keyboard (to define according to the type of transfer),
See SETTING § 1,
4. Set the application time thanks to the keyboard (to define according to the type of transfer),
See SETTING § 1,
5. Adjust the pressure thanks to the regulator (to define according to the type of transfer) ,
See SETTING § 2,
6. Place the item on the inferior plate,
7. Adjust the transfer sheet,
8. Swivel the head of the press using both handles on the sides of the jack support,
9. When the bracket is in full lock, press simultaneously on both push buttons (or on the pedal). Maintain
both buttons until the heating plate is in contact with the inferior plate,
10. At the end of the timer countdown, the heating plate will go back up,
11. Move the heating plate away and remove the item,
12. Start the operation again from n° 6 (if the settings do not change otherwise start again from n°3).
