SEFRAM SF6-36V2 - Front Face Overview; Front Panel Layout; Signalling Indicators; Settings and Output Views

SEQUENCER CONTROLLER
WITH OR WITHOUT
DIFFERENTIAL PRESSURE SWITCH
Technical notice
FI 72.0297.1016E
Page 5
PRESENTATION OF THE FRONT FACE
Note 1: If the option pressure drop measurement is not validated by the presence of the sensor in the equipment, the
front face remains unchanged but the menu steps associated with the pressure drop measurement are not accessible.
Signalling
IN OPTION (note 1)
Settings associated with the pressure
drop measurement
View of the activation
of the S.V. outputs
Settings for the sequencer
parameters
