13
www.seuservice.com
6. ASSEMBLING AND INSTALLATION
● Perform assembly work by following the procedure herein stated. Failing to comply with the
instructions can cause electric shock hazard.
● Perform assembling as per this manual. Since this is a complex machine, erroneous assembling can
cause an electric shock, machine damage and or not functioning as per specified performance.
● When assembling, be sure to use plural persons. Depending on the assembly work, there are some
cases in which working by one person alone can cause personal injury or parts damage.
● Ensure that connectors are accurately connected. Incomplete connections can cause electric shock
hazard.
● Be careful not to damage the wires. Damaged wires may cause electric shock or short circuit or present
a fire risk.
● This work should be performed by the Location's Maintenance Man or Serviceman. Performing work
by non-technical personnel can cause a severe accident such as electric shock. Failing to comply with
this instruction can cause a severe accident such as electric shock to the player during operation.
● Provide sufficient space so that assembling can be performed. Performing work in places with narrow
space or low ceiling may cause an accident and assembly work to be difficult.
● To perform work safely and avoid serious accident such as the cabinet's falling down, do not perform
work in places where step-like grade differences, a ditch, or slope exist.
● Handle molded parts with care. Undue weight or pressure may cause them to break and the
broken pieces may cause injury.
● To perform work safely and securely, be sure to prepare a step which is in a secure and stable
condition. Performing work without using the step can cause violent falling down accidents.
● Make sure that the GD cable connector is inserted parallel to the plug. Improper insertion
may cause damage to the connector and present a fire risk.
SECURING IN PLACE(ADJUSTER ADJUSTMENT)
INSTALLING THE GD-ROM DRIVE(SETTING GD-ROM DISC)
POWER SUPPLY, AND EARTH CONNECTION
TURNING POWER ON
When carrying out the assembling and installation, follow the following 4-item sequence.
WARNING!
CAUTION!
1
2
3
4
Tools such as a Phillips type screwdriver, wrench, socket wrench and Ratchet Handle are
required for the assembly work.
24mm
WRENCH
SOCKET WRENCH,RATCHET HANDLE
Phillips type screwdriver
To Next Page
