Sega OutRun2SP - Page 28

20
www.sauservice.com
SCFIRM
QCFIRM
BDSERIALNO.
FIRMWAREVERSION
GAMEBOARDPARTSNO.
MAINBOARADPARTSNO.
REGION
MEDIABOARDPARTSNO.
BOOTVERSION
PROJECTION
KEYCHIP
MEDIABOARD
Return the ASSY MAIN BD (now installed with the GD-ROM drive) into the PTV cabinet. Fol-
lowing the above-described actions in a reverse order, fix the base, connect the connectors, and
clamp the wires/cables.
FIG. 6. 5 c
Attach the accessory stickers to both the Game Board and the Media Board.
