9. EXPLANATION OF TEST AND DATA DISPLAY
By operating the switch unit, periodically perform the tests and data check. When installing the
machine initially or collecting cash, or when the machine does not function correctly, perform
checking in accordance with the explanations given in this section.
The following shows tests and modes that should be utilized as applicable.
This product's basic system consists of the Chihiro game board and the GD-ROM drive. The
system enables you to play several games one after the other just by changing a GD-ROM disc
that is to be set on the GD-ROM drive.
The product supports, therefore, the following 2 test modes:
(1) System test mode for an automatic self-diagnostic test (generally used by every product that
contains the basic system) and a coin assignment (specifi
cally used by this product) and
(2) Game test mode for testing the input/output control devices and setting the difficulty level
(specifically used by this product).
9-3D
9-3A
9-3B
9-2B, C, D
9-2B, C, D
9-2B, C, D
9-2G, 9-3D
9-3A
9-3B
9-3A
9-3C
10, 1
1, 12
9-2F
14
9-2B, C, D
9-3E
TABLE 9. EXPLANATION OF TEST MODE
ITEMS DESCRIPTION
INSTALLATION
OF MACHINE
MEMOR
Y TEST
PERIODIC
SER
VICING
CONTROL
SYSTEM
MONIT
OR
IC BOARD
DA
TA CHECK
When the machine is installed, perform the following:
1.
Check to ensure each is the standard setting at shipment.
2. Check each Input equipment in the INPUT TEST mode.
3. Check each Output equipment in the OUTPUT TEST mode.
4. Test on-IC-Board IC's in the self-test mode.
This
test is automatically executed by selecting MEDIA BOARD
TEST or SYSTEM INFORMATION in the Menu mode.
Periodically perform the following:
1.
MEMORY TEST
2. Ascertain each setting.
3. To test each Input equipment in the INPUT TEST mode.
4. To test each Output equipment in the OUTPUT TEST mode.
1. To check each Input equipment in the INPUT TEST mode.
2. Adjust or replace each Input equipment.
3. If the problem still remains unsolved, check each equipment's
mechanism movements.
In
the Monitor Adjustment mode, check to see if Monitor (Projec-
tor) adjustments are appropriate.
MEMOR
Y TEST
Check such data as game play time and histogram to adjust the
difficulty level, etc.
REFERENCE
SECTIONS
