4
www.seuservice.com
5
www.seuservice.com
SERVICE BULLETIN
SEGA Service Department http://www.seuservice.com
45133 Industrial Drive Phone: 415.701.6580
Fremont, Ca. 94538 Fax: 415.701.6594
If you have any questions please contact the SEGA Service Department at the numbers given above.
120
Feb 9. 2000
The SEGA Naomi Game kits are actually ‘JAMMA Dependent’. What this means exactly is they will only
install into existing JAMMA Cabinets. If an operator tries to install these kits into a Non-JAMMA cabinet,
they will rst have to bring the wiring up to JAMMA Standards.
° Step 1 Disconnect the games original DC Power Supply. You may only use the power supply
provided
with your kit. Be sure to set the voltages going to your Game BD to 5.1 and 3.3 volts DC to assure proper
operation ( Measure on Square Connector at Game BD. Yellow = 5vdc / Brown = 3.3vdc / White = Gnd )
° Step 2 You MUST USE THE COIN METER SUPPLIED WITH YOUR KIT to assure proper Coin ac-
ceptance. A minimum 18 Gauge wire should be used from the Coin Meter 1 output line on your JAMMA
Harness. The 5vdc ( Yellow ) wire found in the wiring bag of your kit MUST BE USED for the supply
voltage to the meter.
SPECIAL NOTICE FOR
ALL SEGA NAOMI KITS
PROBLEM:
SOLUTION:
Not following the directions provided herein may cause your game to malfunction.
All electrical work should be performed by the site’s Serviceman or Technician.
In order to prevent an electric shock and short circuit, be sure to turn power off before performing work
or touching the interior parts of the product.
Be careful so as not to damage wirings. Damaged wiring can cause an electric shock or short circuit
accident.
Do not touch places other than those specied. Touching places not specied can cause an electric
shock or short circuit accident.
WARNING!
