16-7 GAME BOARD (RINGEDGE) - LOCATION/REMOVAL
1
The machine is tted with a RINGEDGE Game Board. To access the Game board re-
move the Rear Service Door. (The Ringedge is positioned directly behind it).
● Whenreturningthegameboardaftermakingrepairsorreplacements,
makesurethat there are no errorsinthe connection of connectors. Erroneous
connectionscanleadtoelectricalshock,shortcircuitsorres.
● Whenconnectingaconnector,checkthedirectioncarefully.Connectorsmust
beconnectedinonlyonedirection.Ifindiscriminateloadsareappliedinmaking
connections,theconnectororitsterminalxturescouldbedamaged,resultingin
electricalshock,shortcircuitsorres.
● Whenworkingwiththeproduct,besuretoturnthepoweroff.Workingwiththe
poweronmaycauseanelectricshockorshortcircuit.
● Be careful not to damage the wires. Damaged wires may cause an electric
shock,shortcircuitorpresentariskofre.
Ringedge Game Bd
Rear Service Door
