120
PARTS LIST
19
19 PARTS LIST
1 ASSY TOP VIRTUA TENNIS 4 (D-1/5)
ITEM NO PART NO DESCRIPTION QTY
1 4-m-1508 Cabinet Main 1
2 4-m-1511 Back Door LCD 1
3 4-m-1501 Rear Cabinet 1
4 2-6C-0101 Cash Box 1
5 847-0001D-02 Assy Case Edg W 1
6 4-m-1526 Cash box surround 1
7 4-m-0685 Cash box door 1
8 2-4R-0088 Castor Fixed 2
9 4-m-1503 Coin Chute 1
10 4-m-1502 Coin Chute Top 1
11 2-4S-0094-S Locking Tang 1
12 4-m-1525 Back Door Main 1
13 2-4R-0128 Castor swivel 2
14 4-m-0401 Leg Adjuster 2
15 4-m-1517 Control Panel 1
16 4-m-1514 Test / service plate 1
17 2-1C-0045 Meter 1
18 2-8v-0053 Main Glass 1
19 4-m-1512 Glass reinforcement Bkt 1
20 4-m-1500 Foot rest 1
21 2-7S-0087 Coin mech support 1
22 4-m-1510 Control panel fascia 1
23 2-7P-0587 Artwork Monitor Top 1
24 4-m-1513 Speaker grille 2
25 4-m-1504 Coin Chute Lower 1
26 4-m-1506 Metal Frame 1
27 4-m-1509 Metal fascia stainless 2
28 4-m-1516 Monitor bracket upper 2
29 4-m-1523 Coin Entry plate 1
30 4-m-1518 LED strip Billboard 1
31 2-5P-0132 Coin Reject collar 1
32 2-5P-0131 Coin Reject Plunger 1
33 2-5p-0134
Coin Entry Bezel 1
34 6-m-0206 Assy 8Way Joystick Yellow 4
35 4-m-1524 Coin Mech Bracket 1
36 2-1p-0325 Reset Button 2
37 2-1P-0159 SW PB D24 Yellow 4
38 2-1F-0071 Mesh Filter 1
39 2-1P-0354 SW PB D30 Dark Grey 12
40 3-9m-0211 Game Board Wood 1
41 4-m-1529 Speaker mount 2
42 6-E-1199 LED Bar 3
To Next Page
