SEH ProMAX - LED Display and Type Plate; Type Plate Information

Quick Installation Guide [en] 6
LED Display
The LEDs of the UTN server provide information about its status.
Type Plate
The type plate gives important product information, such as hardware and
certification information as well as the serial number. The serial number
contains the production date: nnn YYYY MM nnnnn.
This information helps you e.g. during maintenance and is needed for support
requests as well as for the ’dongleserver ProMAX Serviceplus Package’
3.
LED Action Color Description
Link 1,
Link 2
permanently off
permanently on
blinks at
irregular
intervals
–
green
green
There is no connection to the network.
There is a connection to the network.
There is a connection to the network
and network data packets are being
exchanged.
Activity blinks at
irregular
intervals
yellow Indicates the exchange of UTN
packets.
Status permanently off
blinks 3 times
blinks 2 times
–
green
green
If the activity LED blinks periodically at
the same time, the BIOS mode is
signalized.
Indicates a Zeroconf IP address.
Indicates an IP address that does not
correspond to 0.0.0.0 or that comes
from outside the Zeroconf range.
USB port
1–20
permanently off
permanently on
permanently on
–
green
orange
No USB dongle is connected to the
respective port.
A USB dongle is connected to the
respective port.
The connection to the respective port
and the attached USB dongle is
activated.
Important:
When the device starts up, the behavior of the LEDs
differs from this description.
