36
17. WIRING DIAGRAM
A suggested wiring diagram for installing the Bambi Bucket is given below. (Note: Not for 12 volt 6072 Bambi )
Fig. 37: Control Wiring Diagram
-Switch Button
P/N ESTC-007 - Housing
