52
24.2 Parts List
Diagram# Part No. Description Qty.
1 BB-349 Cable, IDS Deployment, 6072 1
BB-350 Cable, IDS Deployment, 8096 1
BB-350S Cable, IDS Deployment, 8096-1012, short 1
BB-351 Cable, IDS Deployment, 9011,1012 1
BB-352 Cable, IDS Deployment, 1214 1
BB-352S Cable, IDS Deployment, 1214 Short 1
BB-353 Cable, IDS Deployment, 1518-1821 1
2 BB-451 Hub Small Casting 1
3 BB-330 Brackets Restrainer 2
4 BB-299 Cables Hub Restrainer 6072 2
BB-300 Cables Hub Restrainer 8096 2
BB-301 Cables Hub Restrainer 9011/1012/1214 2
BB-302 Cables Hub Restrainer 1518/1821 2
5 BB-454 Brackets shell small 8
6 BB-398 Spokes, IDS, Solid, 6072 2
BB-400 Spokes, IDS, Solid, 8096 2
BB-402 Spokes, IDS, Solid, 9011-1214 2
BB-404 Spokes, IDS, Solid, 1518/1821 2
*7 BB-399 Spokes, IDS, Tube, 6072 6
BB-401 Spokes, IDS, Tube, 8096 6
BB-403 Spokes, IDS, Tube, 9011-1214 6
BB-405 Spokes, IDS, Tube, 1518/1821 6
8 BB-469 Wear Strip, Bracket 8
9 FPCS-004 Clevis Pin (welded hub only) 16
FPCS-004 Clevis Pin (cast hub) 8
FPCS-005 Clevis Pin (cast hub) 8
10 FPDB-001 Cotter Pin 16
11 FWS-0104-0 Flat Washer 16
24. IDS SYSTEM, MODELS 6072-1821
*Note: As of July 2000, all small series buckets
(6072 - 1821) are manufactured with all solid
spokes. If spoke tubes are ordered, solid spokes
will be supplied. (Ref: Design Change No. BA-092)
