40
19.2 Parts List
Diagram Part No. Description Qty.
1 FBSC-040312 Stop bolt 1
FNSC-0103 Nut, Stop bolt 1
2 PPB-002 Bearing 1
3 BB-055 Casting, base, large machined 1
BB-060 Casting, cover, machined 1
4 BB-064 Casting, trip block 1
5 BB-013 Catch 2" long large 1
6 FPCS-005 Clevis pin, bearing 1
7 FPCS-003 Clevis pin, catch 1
8 FPCS-008 Clevis pin, long 1
9 FPCS-002 Clevis pin, short 1
10 FPCS-001 Clevis pin, solenoid 1
11 FPCS-005 Clevis pin, swivel 1
12 BB-003 Link, long Bambi head 2
13 BB-004 Link, short E Bambi head 2
14 BB-005 Link, slotted D Bambi head 1
15 BB-023 Link, spring, large Bambi head 1
16 BB-019A Reel, spring, heavy duty, assembly 1
17 FBSF-070324 Screws, cover 4
FNSC-0203 Nuts, cover 4
18 FTAG-003 Shackle, suspension 2
19 FTAG-005 Shackle, top 1
20 BB-001AL Solenoid and Piston, c/w bolts and nuts 1
21 BB-021 Spring, catch 1
22 BB-022 Spring, return 1
23 PP-010 Terminal block 1
FSS-060206 Screw, terminal block 1
24 BB-387 Trip line assy., 5566-7590 1
25 LB-001 Spec label, cover (Not shown) 1
26 LB-003 Warning label, reel (Not shown) 1
27 BB-067 Lead wire, Bambi head 1
29 FBSC-010414 1/4-20 x 1-1/2 Hex Head Bolt with Hex Nut
30 FBSC-040314 10-24 x 1-1/4 Pan Phil with Hex Nut
31 FBSC0100410 1/4 - 20 x 1" Hex Head Bolt 1
BB590 Head Bambi large aluminium (5566-7590) 1
19. CONTROL HEAD PARTS, MODELS 5566-7590
